- Basic parameters
- Joint bearing 3
- Series
- SBB 20-2RS
- Model
- Main dimensions
- 31.750(1.25)
- d
- 50.800（2)
- D
- 27.76(1.093)
- B
- 23.80( .937)
- C
- 45(1.772)
- dk
- Weight
- 0.234
- Weight/kg
- Radial internal clearance
- 0.08／0.18
- Min./Max.
- Standard mounting size/mm
- 35.1
- d1
- 0.6
- r as max(1) /max
- 0.8
- r bs max(1) /max
- Other parameters
- 105 000
- Basic dynamic load rating Cd/N
- 630 000
- Rated static load Cs/N
