size
| d | 60 | mm | |
| D | 110 | mm | |
| B | 22 | mm | |
| d1 | ≈ | 75.5 | mm |
| D2 | ≈ | 98 | mm |
| D3 | 106.81 | mm | |
| D4 | 116.6 | mm | |
| b | 2.7 | mm | |
| C | 3.28 | mm | |
| f | 2.46 | mm | |
| r0 | max. | 0.6 | mm |
| r1,2 | min. | 1.5 | mm |
Size shoulder size
| da | min. | 69 | mm |
| da | max. | 75.4 | mm |
| Da | max. | 101 | mm |
| Db | min. | 118 | mm |
| ba | min. | 3 | mm |
| Ca | max. | 5.74 | mm |
| ra | max. | 1.5 | mm |
data calculation
| Basic dynamic load rating | C | 56.1 | kN | |
| Basic rated static load | C0 | 50 | kN | |
| Fatigue load limit | Pu | 2.12 | kN | |
| Reference speed | 11000 | r/min | ||
| Maximum speed | 5400 | r/min | ||
| coefficient | kr | 0.04 |
weight
| Bearing weight | 0.85 | kg |
配套产品
| 止动环 | SP 110 | |||
