size
| d | 80 | mm | |
| D | 125 | mm | |
| B | 22 | mm | |
| d1 | ≈ | 94.4 | mm |
| D2 | ≈ | 114.1 | mm |
| D3 | 120.22 | mm | |
| b | 3.1 | mm | |
| C | 2.87 | mm | |
| r0 | max. | 0.6 | mm |
| r1,2 | min. | 1.1 | mm |
Size shoulder size
| da | min. | 86 | mm |
| Da | max. | 119 | mm |
| Db | min. | 136 | mm |
| ba | min. | 3.5 | mm |
| Ca | max. | 5.69 | mm |
| ra | max. | 1 | mm |
data calculation
| Basic dynamic load rating | C | 49.4 | kN | |
| Basic rated static load | C0 | 40 | kN | |
| Fatigue load limit | Pu | 1.66 | kN | |
| Reference speed | 11000 | r/min | ||
| Maximum speed | 7000 | r/min | ||
| coefficient | kr | 0.025 | ||
| coefficient | f0 | 15.6 |
weight
| Bearing weight | 0.84 | kg |
