size
| d | 410 | mm | |
| D | 560 | mm | |
| B | 70 | mm | |
| d1 | ≈ | 468 | mm |
| d2 | ≈ | 441 | mm |
| D1 | ≈ | 504 | mm |
| a | 239 | mm | |
| r1,2 | min. | 4 | mm |
| r3,4 | min. | 1 | mm |
Size shoulder size
| da | min. | 425 | mm |
| Da | max. | 545 | mm |
| Db | max. | 554 | mm |
| ra | max. | 3 | mm |
| rb | max. | 1 | mm |
data calculation
| Basic dynamic load rating | C | 423 | kN | |
| Basic rated static load | C0 | 830 | kN | |
| Fatigue load limit | Pu | 16 | kN | |
| Reference speed | 1100 | r/min | ||
| Maximum speed | 1100 | r/min | ||
| coefficient | A | 10.4 | ||
| coefficient | kr | 0.084 | ||
| coefficient | e | 1.14 | ||
| 单个轴承和串联配置的轴承对 | ||||
| coefficient | X | 0.35 | ||
| coefficient | Y0 | 0.26 | ||
| coefficient | Y2 | 0.57 | ||
weight
| Bearing weight | 49.5 | kg |
