size
| d | 95 | mm | |
| D | 170 | mm | |
| B | 32 | mm | |
| d1 | ≈ | 120 | mm |
| D1 | ≈ | 145 | mm |
| a | 93 | mm | |
| h | 8.1 | mm | |
| b | 6.5 | mm | |
| r0 | 1 | mm | |
| r1,2 | min. | 2.1 | mm |
Size shoulder size
| da | min. | 107 | mm |
| Da | max. | 158 | mm |
| ra | max. | 2 | mm |
data calculation
| Basic dynamic load rating | C | 212 | kN | |
| Basic rated static load | C0 | 232 | kN | |
| Fatigue load limit | Pu | 8.5 | kN | |
| Maximum speed | 6700 | r/min | ||
| coefficient | A | 0.138 | ||
| coefficient | e | 0.95 | ||
| coefficient | X | 0.6 | ||
| coefficient | Y0 | 0.58 | ||
| coefficient | Y1 | 0.66 | ||
| coefficient | Y2 | 1.07 |
weight
| Bearing weight | 3.35 | kg |
