size
| d | 200 | mm | |
| D | 360 | mm | |
| B | 70 | mm | |
| d1 | ≈ | 260 | mm |
| D1 | ≈ | 300 | mm |
| a | 280 | mm | |
| h | 12.7 | mm | |
| b | 10.55 | mm | |
| r0 | 2 | mm | |
| r1,2 | min. | 4 | mm |
Size shoulder size
| da | min. | 218 | mm |
| Da | max. | 384 | mm |
| ra | max. | 3 | mm |
data calculation
| Basic dynamic load rating | C | 520 | kN | |
| Basic rated static load | C0 | 865 | kN | |
| Fatigue load limit | Pu | 21.6 | kN | |
| Maximum speed | 3000 | r/min | ||
| coefficient | A | 4.41 | ||
| coefficient | e | 1.34 | ||
| coefficient | X | 0.54 | ||
| coefficient | Y0 | 0.44 | ||
| coefficient | Y1 | 0.47 | ||
| coefficient | Y2 | 0.81 |
weight
| Bearing weight | 32.5 | kg |
