size
| D | 72 | mm | |
| d | 24 | mm | |
| B | 80 | mm | |
| C | 28 | mm | |
| B1 | 49.5 | mm | |
| B2 | 11 | mm | |
| C1 | 1.3 | mm | |
| d1 | 44 | mm | |
| G | M 24x1.5 | ||
| G1 | 25 | mm | |
| M | 8 | mm | |
| M1 | 4 | mm | |
| SW | 14 | mm | |
| r1,2 | min. | 1.1 | mm |
data calculation
| Basic dynamic load rating | C | 39.6 | kN | |
| Basic rated static load | C0 | 45 | kN | |
| Fatigue load limit | Pu | 5.6 | kN | |
| 最大径向动态载荷 | Fr | max. | 47.5 | kN |
| 最大静态径向载荷 | F0r | max. | 68 | kN |
| Maximum speed | 2600 | r/min |
weight
| 螺栓型圆柱滚子滚轮轴承的weight | 1.02 | kg |
安装信息
| 建议锁紧扭矩 | 220 | N·m |
配套产品
| 润滑油嘴 | NIP A3x9.5 | |||
| 六角螺母 | M 24x1.5 | |||
适用产品
| 润滑适配器 | AP 14 | |||
