size
| D | 26 | mm | |
| d | 10 | mm | |
| B | 36 | mm | |
| C | 12 | mm | |
| B1 | 23 | mm | |
| C1 | 0.6 | mm | |
| d1 | 17.5 | mm | |
| G | M 10x1 | ||
| G1 | 12 | mm | |
| M | 4 | mm | |
| SW | 5 | mm | |
| r1,2 | min. | 0.3 | mm |
data calculation
| Basic dynamic load rating | C | 4.84 | kN | |
| Basic rated static load | C0 | 6 | kN | |
| Fatigue load limit | Pu | 0.655 | kN | |
| 最大径向动态载荷 | Fr | max. | 9.3 | kN |
| 最大静态径向载荷 | F0r | max. | 13.2 | kN |
| Maximum speed | 5300 | r/min |
weight
| 螺栓型圆柱滚子滚轮轴承的weight | 0.057 | kg |
安装信息
| 建议锁紧扭矩 | 15 | N·m |
配套产品
| 润滑油嘴 | NIP A1x4.5 | |||
| 六角螺母 | M 10x1 | |||
