size
| D | 16 | mm | |
| d | 6 | mm | |
| B | 28 | mm | |
| C | 11 | mm | |
| B1 | 16 | mm | |
| C1 | 0.6 | mm | |
| d1 | 12.5 | mm | |
| G | M 6 | ||
| G1 | 8 | mm | |
| M | 4 | mm | |
| r1,2 | min. | 0.15 | mm |
data calculation
| Basic dynamic load rating | C | 3.14 | kN | |
| Basic rated static load | C0 | 3.2 | kN | |
| Fatigue load limit | Pu | 0.345 | kN | |
| 最大径向动态载荷 | Fr | max. | 2.9 | kN |
| 最大静态径向载荷 | F0r | max. | 4.15 | kN |
| Maximum speed | 6000 | r/min |
weight
| 螺栓型圆柱滚子滚轮轴承的weight | 0.019 | kg |
安装信息
| 建议锁紧扭矩 | 3 | N·m |
配套产品
| 润滑油嘴 | NIP A1 | |||
| 六角螺母 | M 6x1 | |||
适用产品
| 插头 | VD1 | |||
