size
| D | 52 | mm | |
| d | 20 | mm | |
| B | 66 | mm | |
| C | 24 | mm | |
| B1 | 40.5 | mm | |
| B2 | 9 | mm | |
| C1 | 0.8 | mm | |
| d1 | 36.5 | mm | |
| G | M 20x1.5 | ||
| G1 | 21 | mm | |
| M | 6 | mm | |
| M1 | 4 | mm | |
| SW | 10 | mm | |
| r1,2 | min. | 1 | mm |
data calculation
| Basic dynamic load rating | C | 15.7 | kN | |
| Basic rated static load | C0 | 27 | kN | |
| Fatigue load limit | Pu | 3.2 | kN | |
| 最大径向动态载荷 | Fr | max. | 36 | kN |
| 最大静态径向载荷 | F0r | max. | 51 | kN |
| Maximum speed | 3000 | r/min |
weight
| 螺栓型圆柱滚子滚轮轴承的weight | 0.45 | kg |
安装信息
| 建议锁紧扭矩 | 120 | N·m |
配套产品
| 润滑油嘴 | NIP A2x7.5 | |||
| 六角螺母 | M 20x1.5 | |||
适用产品
| 润滑适配器 | AP 10 | |||
