size
| D | 35 | mm | |
| d | 20 | mm | |
| B | 52 | mm | |
| C | 18 | mm | |
| B1 | 29.5 | mm | |
| B2 | 7.8 | mm | |
| B3 | 12 | mm | |
| C1 | 3.8 | mm | |
| d1 | 27.6 | mm | |
| G | M 16x1.5 | ||
| G1 | 17 | mm | |
| M | 6 | mm | |
| M1 | 3 | mm | |
| SW | 8 | mm | |
| c | 1 | mm | |
| r1,2 | min. | 0.6 | mm |
data calculation
| Basic dynamic load rating | C | 11.9 | kN | |
| Basic rated static load | C0 | 11.4 | kN | |
| Fatigue load limit | Pu | 1.2 | kN | |
| 最大径向动态载荷 | Fr | max. | 8.65 | kN |
| 最大静态径向载荷 | F0r | max. | 12.5 | kN |
| Maximum speed | 5000 | r/min |
weight
| 螺栓型圆柱滚子滚轮轴承的weight | 0.18 | kg |
安装信息
| 建议锁紧扭矩 | 58 | N·m |
配套产品
| 润滑油嘴 | NIP A2x7.5 | |||
| 六角螺母 | M 16x1.5 | |||
适用产品
| 润滑适配器 | AP 8 | |||
