size
| d | 40 | mm | |
| D | 80 | mm | |
| B | 23 | mm | |
| d2 | ≈ | 52.4 | mm |
| D1 | ≈ | 69.9 | mm |
| s1 | max. | 7.1 | mm |
| s2 | max. | 4.1 | mm |
| r1,2 | min. | 1.1 | mm |
Dimensions
Size shoulder size
| da | min. | 47 | mm |
| da | max. | 66 | mm |
| Da | max. | 73 | mm |
| ra | max. | 1 | mm |
data calculation
| Basic dynamic load rating | C | 102 | kN | |
| Basic rated static load | C0 | 104 | kN | |
| Fatigue load limit | Pu | 12.2 | kN | |
| Maximum speed | 4500 | r/min | ||
| 不对中系数 | k1 | 0.093 | ||
| 运行游隙系数 | k2 | 0.128 |
weight
| 轴承weight | 0.53 | kg |
