size
| d1 | 360 | mm | |
| D | 560 | mm | |
| B | 135 | mm | |
| B1 | 170 | mm | |
| d2 | ≈ | 431 | mm |
| D1 | ≈ | 512 | mm |
| B2 | ≈ | 180 | mm |
| G | Tr 400x5 | ||
| G1 | 31 | mm | |
| s1 | max. | 27 | mm |
| r1,2 | min. | 5 | mm |
Dimensions
Value specified for B2 is approximate and before the sleeve is driven into the bearing bore.
Size shoulder size
| da | min. | 390 | mm |
| da | max. | 462 | mm |
| Da | min. | 491 | mm |
| Da | max. | 542 | mm |
| Ca | min. | 2 | mm |
| ra | max. | 4 | mm |
- Ca 理论上是负值。
data calculation
| Basic dynamic load rating | C | 3000 | kN | |
| Basic rated static load | C0 | 5200 | kN | |
| Fatigue load limit | Pu | 380 | kN | |
| Reference speed | 900 | r/min | ||
| Maximum speed | 1200 | r/min | ||
| 不对中系数 | k1 | 0.12 | ||
| 运行游隙系数 | k2 | 0.1 |
weight
| Bearing weight + 紧定套 | 130 | kg |
