size
| d | 65 | mm | |
| D | 120 | mm | |
| B | 31 | mm | |
| d2 | ≈ | 79 | mm |
| D1 | ≈ | 106 | mm |
| s1 | max. | 9.6 | mm |
| s2 | max. | 5.3 | mm |
| r1,2 | min. | 1.5 | mm |
圆锥孔，锥度 1:12
Dimensions
Size shoulder size
| Da | max. | 111 | mm |
| ra | max. | 1.5 | mm |
data calculation
| Basic dynamic load rating | C | 204 | kN | |
| Basic rated static load | C0 | 216 | kN | |
| Fatigue load limit | Pu | 25.5 | kN | |
| Maximum speed | 2400 | r/min | ||
| 不对中系数 | k1 | 0.097 | ||
| 运行游隙系数 | k2 | 0.127 |
weight
| 轴承weight | 1.45 | kg |
