size
| d1 | 200 | mm | |
| D | 340 | mm | |
| B | 118 | mm | |
| B1 | 138 | mm | |
| d2 | ≈ | 251 | mm |
| D1 | ≈ | 306 | mm |
| B2 | ≈ | 152 | mm |
| G | Tr 230x4 | ||
| G1 | 20 | mm | |
| s1 | max. | 20 | mm |
| s2 | max. | 10.1 | mm |
| r1,2 | min. | 3 | mm |
Dimensions
Value specified for B2 is approximate and before the sleeve is driven into the bearing bore.
Size shoulder size
| da | min. | 228 | mm |
| da | max. | 284 | mm |
| Da | max. | 327 | mm |
| ra | max. | 2.5 | mm |
data calculation
| Basic dynamic load rating | C | 1930 | kN | |
| Basic rated static load | C0 | 3250 | kN | |
| Fatigue load limit | Pu | 280 | kN | |
| Maximum speed | 200 | r/min | ||
| 不对中系数 | k1 | 0.115 | ||
| 运行游隙系数 | k2 | 0.095 |
weight
| Bearing weight + 紧定套 | 48 | kg |
